FN-100
Seam Welding Machine
Roll seam welder for airtight welding of medium-thickness duct sheets
FN-100
Seam Welding Machine
Roll seam welder for airtight welding of medium-thickness duct sheets
The FN-100 seam welding machine is a high-performance welding device designed specifically for continuous seam welding of medium-thickness duct pipes. It can perform welding on both stainless steel and low carbon steel of medium thickness, with a maximum welding capacity of 1.5mm + 1.5mm sheet thickness. It features stepless adjustment of secondary voltage, simple and convenient operation, and stable welding speeds ranging from 0.6-2.5m/min. It efficiently produces uniform, firm, and sealed welds, making it an ideal choice for manufacturing metal housings and cylindrical bodies.
Applications
The FN-100 seam welding machine is suitable for longitudinal straight seam sealing welding of stainless steel duct pipes, such as circular or rectangular duct joint welding.
Request a Quote
Features
- Rated capacity of 100kVA, capable of seamlessly welding 1.5mm+1.5mm low carbon steel and stainless steel, with a single weld length up to 600mm, meeting most medium-thickness sheet welding requirements.
- Stepless adjustment of secondary voltage and continuously adjustable welding speed from 0.6-2.5m/min provide strong process adaptability and low operator skill requirements, easily achieving high-quality welds.
- Provides 8kN of constant electrode pressure, combined with precise compressed air control (0.5-2.2MPa), ensuring stable contact resistance and uniform, firm, and well-sealed welds during the process.
- This seam welding machine supports continuous seam welding tasks for multiple metal materials, making it a durable duct pipe welding machine.
Specifications
- Rated capacity100kVA
- Rated primary voltage/phase380V/1 (2 live wires)
- Rated frequency50Hz
- Rated current263A
- Electrode stroke60mm
- Welding speed0.6-2.5m/min
- Electrode pressure8kN
- Welding capability (Low carbon steel)1.5+1.5, length 600mm
- Welding capability (Stainless steel)1.5+1.5, length 600mm
- Secondary voltage adjustmentStepless
- Compressed air pressure0.5-2.2MPa
- Machine weight500kg
